Description
This splitter by Delock receives a HDMI signal from a PC or laptop and splits it to four connected displays. Thereby one HDMI connection can be used to operate four HDMI monitors.
Specification
Connector:
Input:
1 x HDMI-A 19 pin female
1 x DC 5 V power connector
Output:
4 x HDMI-A 19 pin female
High Speed HDMI specification
Supports 3D displays
Supports HDCP 1.4 and 2.2
Supports HDR
Reset button
LED indicator
Supports a resolution up to 3840 x 2160 @ 60 Hz
(depending on the system and the connected hardware)
Video bandwidth up to 600 MHz / 6 Gbps, 18 Gb/s max.
Power consumption: max. 2.4 W
Metal housing
Colour: black
Dimensions (LxWxH): ca. 123 x 51 x 20 mm
Power supply specification
Wall power supply
Input: AC 100 ~ 240 V / 50 ~ 60 Hz / 0.3 A
Output: 5 V / 1 A
Ground outside, plus inside
Dimensions:
inside: o ca. 2.1 mm
outside: o ca. 5.5 mm
length: ca. 9 mm
System requirements
A free HDMI female port
HDMI cable
Package content
HDMI Splitter
USB power cable, length: ca. 0.5 m
External power supply
User manual
Package
Retail Box
Artikel-Nr. 18684
EAN: 4043619186846
